Interface Converter Signal Tower 40mm
PHE-3FB3

Connect the PHE-3FB3 Interface Converter Signal Tower to your PC via USB or RS-232C. It features three-color, two-pattern signals, four alarm sounds, and a reset switch for easy operation.

  • USB (Bus power)
  • RS-232C
  • Signal Tower
  • Φ40
  • Continuous on
  • Flashing (Strobe)
  • Alarm
  • 80dB or more
  • Interface Converter
  • Indoor
  • IP20
  • Red
  • Amber
  • Green
  • Interface Converter Signal Tower 40mm PHE-3FB3
  • It can be connected to a personal computer via the USB or RS-232C port.
  • Each product is equipped with a reset switch to easily and quickly return it to its initial state.
  • Usability is streamlined due to a simpler communication protocol.
  • A signal tower with three colours and two flashing patterns that are independently controllable.
  • Can control four built-in alarm sounds with sound levels of 80 dB or more (at 1m).

This product requires a program which creates the data output from the USB/RS-232C port of a personal computer.
The USB Cable (type A male to type B male) is not included.
Please purchase separately.



Model Specifications

CONFORMITY STANDARDS - RoHS Directive (EN IEC 63000)
- EMC Directive (EN 61000-6-4 (Class A), EN 61000-6-2)
- FCC Part15 Subpart B Class A, ICES-003 Class A
- UL 60950-1 CAN/CSA C22.2 No.60950-1
- PSE Compliant AC Adaptor (N Type excluded)

CE Marking
UL/cUL Listed: PHE-3FB3-RYG
UL/cUL Recognized Component: PHE-3FB3N-RYG
Model Code
